Classic Rib


Panel Coverage: 36"
Rib Height: 3/4"
Rib Features: Bell top trapezoidal rib on 9" centers
Standard Gauge(s): 26 ga.29 ga.
This exposed fastened, low-profile panel applies over open framing or solid substrate.
Available Substrate(s): Open FramingSolid Substrate
Fastener(s): Exposed Fastened
Standard Finish(es): PVDF (Kynar 500 )MS Colorfast45 Acrylic Coated Galvalume Bare Galvanized
Minimum Slope Requirement: 3:12
Other Notes:
Exposed fastened, low profile panel
25-Year Galvalume Warranty
Finish Warranty / MS Colorfast45
PVDF Flurocarbon System Warranty
Rib Height: 3/4"
Rib Features: Bell top trapezoidal rib on 9" centers
Standard Gauge(s): 26 ga.29 ga.
This exposed fastened, low-profile panel applies over open framing or solid substrate.
Available Substrate(s): Open FramingSolid Substrate
Fastener(s): Exposed Fastened
Standard Finish(es): PVDF (Kynar 500 )MS Colorfast45 Acrylic Coated Galvalume Bare Galvanized
Minimum Slope Requirement: 3:12
Other Notes:
Exposed fastened, low profile panel
Warranty
25-Year Galvalume Warranty
Finish Warranty / MS Colorfast45
PVDF Flurocarbon System Warranty
Available Colors
29 Guage
Galvanized
MS Strongcoat45
ColorFit40
